Ruby

Ruby

Chair / Barstool

Ruby

Chair / Barstool

A simple, supportive sit with designed-in versatility.

Designed by NaughtOne

With its seamless shell seat, the Ruby seating range is comfortable, durable and effortlessly adaptable. Place Ruby in a collaborative work zone, at the island in an office kitchen, around a table in a university library, or in a cafe. Wherever it touches down, Ruby is right at home.


Simple design that lasts

Available as a task chair, counter-height stool and barstool, Ruby features a hardwearing polypropylene shell that can be wiped down in moments. NaughtOne’s wide range of shell seat colours and base options adds to its versatility for specifiers.


Get comfy

Ruby’s smooth shell, considered form and wide sit make it deceptively comfortable – with or without seatpad.

Resources

CAD Files

CAD Files

naughtone_Extended_Brochure_Ruby.pdf

Product Sheet

Images

Images

“Effortlessly adaptable and a mood enhancer for workspaces, hospitality, education and shared settings.”

Specifications

RUBYCHB4L

RUBYCHB4L

Ruby Chair
4 Leg Base
w610 d540 h785
weight 7.28 kg
seat 430 (mm)
w24 d21.5 h31
seat 17 (in)
weight 16.05 lb

RUBYCHBSL

RUBYCHBSL

Ruby Chair
Sled Base
w610 d530 h785
seat 430 (mm)
weight 10.75 kg
w24 d21 h31
seat 17 (in)
weight 23.69 lb

RUBYCHBDL

RUBYCHBDL

Ruby Chair
Dowel Base
w610 d530 h785
seat 430 (mm)
weight 6.85 kg
w24 d21 h31
seat 17 (in)
weight 15.1 lb

RUBYCHSB4L

RUBYCHSB4L

Ruby Counter
Height Stool
w610 d530 H 995
seat 640 (mm)
weight 9.33 kg
w24 d21 h39
seat 25 (in)
weight 20.56 lb

RUBYBSB4L

RUBYBSB4L

Ruby Barstool
4 Leg Base
w610 d535 h1095
seat 730 (mm)
weight 9.64 kg
w24 d21 h43
seat 25 (in)
weight 20.56 lb

RUBYCHSBSL

RUBYCHSBSL

Ruby Counter Height
Stool on Sled Base
w610 d540 h995
seat 640 (mm)
weight 11.37 kg
w24 d21.5 h39
seat 25 (in)
weight 25.07 lb

RUBYBSBSL

RUBYBSBSL

Ruby Barstool
on Sled Base
w610 d565 h1090
seat 730
weight 11.83kg
w24 d22 h43
seat 28.5
weight 26.07 lb

NaughtOne RAL palette

Traffic Red
RAL 3020

Broom Yellow
RAL 1032

Moss Green
RAL 6005

Pale Green
RAL 6021

Pastel Blue
RAL 5024

Steel Blue
RAL 5011

Oyster
RAL 1013

Signal White
RAL 9003

Stone Grey
RAL 7030

Black Grey
RAL 7021

4 Star Base<br />
White / Black/ Polished<br />
Standard

4 Star Base
White / Black/ Polished
Standard

4 Star Base<br />
RAL Powder Coated<br />
NaughtOne Colours

4 Star Base
RAL Powder Coated
NaughtOne Colours

5 Star Base<br />
White / Black/ Polished<br />
Standard

5 Star Base
White / Black/ Polished
Standard

5 Star Base<br />
RAL Powder Coated<br />
NaughtOne Colours

5 Star Base
RAL Powder Coated
NaughtOne Colours

5 Star Base<br />
Gas Lift mechanism

5 Star Base
Gas Lift mechanism

The Ruby chair is available in a range of finishes but for the purpose of this statement we have a specific example from the range: Ruby Chair with 4 leg base.

Recyclable Content
100% Recyclable
Recycled Content
27.9% Recycled
57.35% ALUMINIUM
35.67% POLYPROPYLENE
4.57% MILD STEEL
2.2% NYLON
0.5% STAINLESS STEEL
0.5% MILD STEEL ZINC PLATED

The cold cure foam material has been tested to meet the following standards:

— British standard: 5852:2006 Part 2
— California Technical Bulletin: 117-2013
— Italian standard: UNI 9175-CLASS 1.IM

The flammability standard of the covering fabric is dependent on the choice made by the customer.

RUBYCHB4L
Ruby Chair on 4 Leg Base
BS EN 16139,2013, Level 2
Static Load 200 kg
ANSI/BIFMA X5.4 – 2012
Static Load 300 lb
RUBYCHBDL
Ruby Chair on Dowel Base
BS EN 16139,2013, Level 2
Static Load 200 kg
ANSI/BIFMA X5.4 – 2012
Static Load 300 lb

Choice comes as standard

Choice comes as standard

A NaughtOne design isn’t just an expression of our creativity – it’s a canvas for expressing your creativity. Which is why Ruby, like all NaughtOne products, can be specified in a near endless array of finishes.

Create hotspots with bright color pops, make a statement with patterns, or blend in with cool neutrals.
